Overview
F-16E/F
The F-16E/F, also known as the Block 60, is a variant of the F-16 Fighting Falcon developed for the United Arab Emirates. It features advanced avionics, including the AN/APG-80 AESA radar, and is powered by the General Electric F110-GE-132 engine. The aircraft is equipped with conformal fuel tanks, enhancing its range and endurance. It also includes advanced electronic warfare systems and a modular mission computer. The F-16E/F is capable of carrying a wide range of weapons and is designed for multirole operations.
Specifications

General

Crew2
RadarAN/APG-80 AESA
Engines1
StealthNo
Thrust Kn144.6 kN
Air To AirAIM-120 AMRAAM, AIM-9 Sidewinder
Hardpoints11
Internal GunM61A1 20mm cannon
Air To GroundGBU-12 Paveway II, AGM-65 Maverick
Ferry Range Km4,220 km
Max Payload Kg7,700 kg
Max Speed Mach2 Mach
Combat Radius Km1,389 km
Service Ceiling M15,240 m

Other

Length M15.03 (49 ft 4 in)
Powerplant1 × General Electric F110-GE-132 afterburning turbofan, 32,500 lbf (144.6 kN) class
Wingspan M9.45 (31 ft 0 in)
Units Built80 (55 F-16E single-seat, 25 F-16F two-seat)
Targeting SystemAN/ASQ-28 Internal FLIR and Targeting System (IFTS), nose-mounted
Electronic WarfareNorthrop Grumman Falcon Edge integrated internal EW suite, up to 8 chaff/flare dispensers
Conformal Fuel Tanks2 × dorsal CFTs, ~1,360 kg (3,000 lb) additional internal fuel
Max Takeoff Weight Kg20,865 (46,000 lb)
Latest Developments
Oct 21, 2026strong signal
Saudi Arabia and the UAE Reassess Joint Gulf Defense Test After Escalation of Regional Attacks

الإمارات بنت قوة جوية صغيرة لكنها عالية النوعية حول F-16E/F ووسائط الاستطلاع والدفاع الجوي

Mar 31, 2026strong signal
Eurofighter Typhoon Outclimbs the F-16 and Closes In on the F-22 Raptor — Without a Single Stealth Feature

Entity 'F-16 Fighting Falcon' mentioned in report

Mar 27, 2026strong signal
Move Over, Stealth F-35: Canada’s CF-18 Fighter Is Getting a Big Missile Upgrade

Entity 'F-16' mentioned in report

Mar 25, 2026strong signal
Japan Offered to Build Its Own F-22 Raptor Variant — One Congressional Amendment From 1998 Banned the Sale and Changed Asia’s Air Power Forever

Fighters like the F-16 and F-15 were widely exported to countries friendly to the United States, as was the later F-35, a fifth-generation multirole fighter.

Mar 24, 2026strong signal
Europe's Defense Industrial Awakening: Navigating the Tension Between Autonomy and Transatlantic Partnership

American production capacity currently supplies air defense systems, interceptor missiles, F-16 ammunition, and spare parts that European manufacturers cannot deliver at necessary scale or speed.

Mar 18, 2026strong signal
Domestic-related shooting leaves 1 dead, another injured at New Mexico Air Force base

The wing also trains F-16 Fighting Falcon pilots and MQ-9 Reaper pilots and sensor operations.

Featured Coverage
Research Notes

UAE-specific Desert Falcon branch of the F-16 family

medium

The F-16E/F is best understood as the Block 60 Desert Falcon configuration developed for the United Arab Emirates, not as a generic F-16 label.

The F-16E/F page should be read as a specific branch of the wider F-16 family. Public references commonly associate the E/F designation with the Block 60 Desert Falcon aircraft delivered to the United Arab Emirates, with single-seat F-16E and two-seat F-16F forms.

That matters because the E/F designation does not simply mean a later version of every F-16. It points to a high-end national configuration built around UAE requirements, with distinctive avionics, sensors, fuel, and mission-system features compared with many earlier F-16C/D aircraft.

For HiWars, this page should connect back to the F-16 parent page but avoid duplicating it. The parent page explains the global family; the F-16E/F page explains the UAE Block 60 path and why national configurations matter.

High-end F-16 configuration with national integration choices

medium

F-16E/F capability depends on its Block 60 avionics, sensors, conformal fuel, weapons integration, and UAE sustainment arrangements.

The wider F-16 family is known for upgradeability, weapons integration, and a mature support ecosystem. The F-16E/F Block 60 path pushed that family toward a more advanced national configuration, including avionics and sensor choices tailored to one operator.

Because this is not the main U.S. Air Force F-16 standard, readers should be careful with comparisons. A Block 60 Desert Falcon, an F-16V, a Block 50/52 aircraft, and an older F-16A all share lineage but may differ significantly in radar, cockpit, mission computer, fuel configuration, weapons, and electronic systems.

This is exactly why variant pages matter. They prevent the database from flattening a very large aircraft family into a single generic F-16 capability.

What the designation tells readers

medium

F-16E/F is useful as a record because it points to an operator-specific capability package rather than just a new letter.

The practical value of this record is interpretive. When readers see F-16E/F in an inventory or event record, they should understand that it likely refers to the UAE's Desert Falcon branch rather than the ordinary U.S. F-16C/D fleet.

That affects how capability is read. The aircraft's value depends on UAE weapons stocks, maintenance, pilot training, basing, mission planning, and upgrades, not just on the model designation.

Future HiWars updates should connect this record to UAE Air Force inventory, known weapons integration, modernization status, and whether similar technologies influenced later F-16V or Block 70/72 offerings.

Key parameters at a glance

high

Figures reflect the UAE-specific Block 60 configuration as published by Lockheed Martin and the programme's suppliers; items marked (reported) come from press coverage rather than manufacturer data.

Role
Single-seat (F-16E) and two-seat (F-16F) multirole fighter; the F model has a fully missionised rear cockpit
Sole operator
United Arab Emirates Air Force and Air Defence — 80 aircraft, no other customer
Radar
Northrop Grumman AN/APG-80 AESA, approx. 1,000 transmit/receive modules; the first AESA fitted to any F-16
Radar performance
Roughly twice the range of the mechanically scanned AN/APG-68, with simultaneous air-to-air, air-to-ground and terrain-following modes
Engine
General Electric F110-GE-13232,500 lbf / 144.6 kN with afterburner
Conformal fuel tanks
Two dorsal CFTs adding about 1,360kg (3,000 lb) of internal fuel
Internal sensor
AN/ASQ-28 IFTS — nose-mounted FLIR and laser system replacing the external navigation pod, feeding the HUD and rear cockpit
Electronic warfare
Northrop Grumman Falcon Edge integrated internal EW suite with EW management system and up to eight chaff/flare dispensers
Cockpit and avionics
Three 5 × 7 in colour multifunction displays, fibre-optic avionics data bus, Advanced Mission Computer
Development funding
Roughly US$3 billion of Block 60 development paid for by the UAE (reported)

Program milestones

high

Publicly reported milestones of the UAE Desert Falcon programme and its follow-on upgrade efforts.

1998Abu Dhabi selects the Block 60

After a competition against European types, the UAE chose Lockheed Martin's proposed Block 60 F-16 with dorsal conformal fuel tanks and an AESA radar, agreeing to fund the development itself.

2000-03US$6.4bn contract for 80 aircraft

Contracts signed on 5 March 2000 covered 55 single-seat and 25 two-seat aircraft plus support. The General Electric F110-GE-132 was announced as the powerplant days later.

2003-12First flight

The first Block 60 flew on 6 December 2003 at Fort Worth, entering Lockheed Martin flight test in early 2004.

2005-05First deliveries to the UAE

Deliveries began in May 2005 after the initial pilot cadre completed training with the Arizona Air National Guard, making the UAE the first air force outside the United States to field an AESA-equipped fighter.

2011-03First combat deployment

Six Block 60s deployed to Decimomannu, Italy alongside Mirage 2000-9s to support enforcement of the no-fly zone over Libya; the type had crossed the Atlantic for Red Flag 11-2 weeks earlier.

2014-01Block 61 foreign military sale notified

The US Defense Security Cooperation Agency notified Congress of a possible sale of 30 F-16 Block 61 aircraft with associated equipment and support; the new-build order was never converted into a contract.

2017-11US$1.6bn upgrade and sustainment contract

Announced at the Dubai Airshow, the package covers upgrades, spares and support for the 80-aircraft Block 60 fleet, addressing obsolescence in the original avionics.

2021-12Rafale order reshapes the fleet plan

The UAE ordered 80 Dassault Rafale F4s, removing the rationale for additional new-build Block 61 Vipers and positioning the upgraded Block 60 as the second-line multirole fleet.

Strategic significance

medium

The Block 60 is best understood as a customer-funded technology forcing function rather than another export batch. By paying for development itself, the UAE obtained an F-16 that in 2005 carried sensors the US Air Force did not yet operate on the type — an AESA radar, an internally mounted FLIR and targeting system, and an integrated internal electronic warfare suite. Contemporary reporting framed this as the first time Washington had released a fighter configuration more capable in some respects than the one its own squadrons flew, and the aircraft remains the only F-16 subvariant designed around conformal fuel tanks and internal sensors from the outset.

Operationally the pay-off is reach and sortie persistence rather than raw kinematics. The dorsal conformal tanks add roughly 1,360 kg of internal fuel at far lower drag than centreline and wing tanks, freeing stations for weapons, while the internal IFTS removes one pod from the airframe and leaves the intake hardpoints available for a targeting pod. The cost is weight: empty weight rises to around 22,000 lb and maximum take-off weight to 46,000 lb, which is why the uprated F110-GE-132 was required. In practice the Desert Falcon trades some instantaneous agility for range, sensor coverage and growth margin — a sensible bargain for a Gulf air force whose likely missions are long-range strike and standing air defence over water and desert.

Two decades on, the fleet's significance is shifting. The 30-aircraft Block 61 follow-on notified in 2014 was never contracted, and the UAE's 2021 Rafale F4 purchase, together with the stalled F-35 discussion, means the Block 60 is now a sustainment and obsolescence problem rather than a growth line — the rationale for the 2017 upgrade and support package. Its lasting influence is architectural: the conformal-tank, AESA and internal-sensor formula pioneered on the Block 60 anticipated much of what later became the F-16V and Block 70/72 standard now being sold across the world.
